2MPIP-2MIR100055X 2MP 55x Darklight Laser IR Network Positioning System

2MPIP-2MIR100055X 2MP 55x Darklight® Laser IR Network Positioning System

Features:

55X Optical Zoom(6.4~352mm)
Starlight illumination
Support Optical defog, Self-adaptive defog
Day/night functionality
Vari-focal laser: 1000m (3280ft) distance, proportional to optical zoom of camera module
Gyroscope stabilization for stable picture
Up to 120 dB Optical WDR(Wide Dynamic Range)
Optical glass window with higher light transmittance
IR anti-reflection window to increase the infrared transmittance
2D/3D DNR (Digital Noise Reduction)
Ultra 265, H.265, H.264, MJPEG
Support 1080P@60fps, which has the smoother motion image
Triple streams
ROI (Region of Interest)
ONVIF Conformance
Intelligent temperature control technology
Support automatic wiper function
Embedded gradienter to ensure the horizontal position while installation
Wide temperature range: -40°C to 70°C (-40°F to 158°F)
Power supply: DC 48V±25%/DC 24V±15%(DC20V~DC60V), DC -48V±25%/ DC -24V±15%(DC-20V~-DC-60V), AC 24V±25%
Support 1/1 audio in/out, 7/2 alarm in/out ,1 Serial port RS485,1 BNC
Support up to 256G Micro SD card
Ingress Protection: IP66 Ingress Protection: IP66

Country of Origin	China

CAMERA
Sensor		1/2.8″ progressive scan, 2.0megapixel, CMOS
Lens		6.4~352mm, AF automatic focusing and motorized zoom lens
Digital Zoom		16
Optical Zoom		55
DORI Distance	Lens	Detect(m)	Observe(m)	Recog- nize(m)	Identify(m)
	6.4mm	99.3(30.3ft)	39.7(12.1ft)	19.9(6.1ft)	9.9(3.0ft)
	352mm	5462.1 (1664.8ft)	2184.8 (655.0ft)	1092.4 (333.0ft)	546.2 (166.5ft)
Angle of View (H)		42.0° ~ 1°
Angle of View (V)		34.8°~0.5°
Angle of View (O)		51.6°~1.1°
Shutter		Auto/Manual, shutter time: 1s ~ 1/100000 s
Minimum Illumination		0.002lux (F1.8, AGC ON, Color), 0 lux with IR
Iris		F1.8 ~ F6.5
Day/Night		IR-cut filter with auto switch(ICR)
Digital noise reduction		2D/3D DNR
S/N		>52 dB
Defog		Optical Defog
WDR		120dB
IR Distance		1000m(3280ft)
VIDEO
Video Compression		Ultra 265, H.265, H.264, MJPEG
Frame Rate		Main Stream:2MP (1920×1080)@60fps Sub Stream:2MP(1920×1080)@60fps; Third Stream:D1(720×576)@60fps
HLC		Supported
BLC		Supported
Gyroscope		Supported
OSD		Up to 8 OSDs
Privacy Mask		Up to 24 areas
ROI		Up to 8 areas
Motion Detection		Up to 4 areas
SMART
General Function		Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
AUDIO
Audio Compression		G.711U, G.711A
Two way audio		Supported

STORAGE
Edge Storage	Micro SD, up to 256 GB
Network Storage	ANR
NETWORK
Protocols	IPv4, HTTP, HTTPS, SSL/TLS, FTP, SMTP, SNMPV1/V2/V3(MIB-II), DNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP
Compatible Integration	ONVIF(Profile S, Profile G, Profile T), API
PAN & TILT
Pan Range	360°
Pan Speed	0.1°/s ~140°/s
Pan Speed	Preset speed: 140°/s
Tilt Range	–90° ~ +45°
Tilt Speed	0.1° ~50°/s
Tilt Speed	Preset speed:50°/s
Number of Presets	1024
Patrol	Preset patrol, route patrol, recorded patrol
Power-off memory	Supported
Keep watch	Supported
INTERFACE
Audio I/O	1 Input: impedance 35 kΩ; amplitude2 V [p-p]
Audio I/O	1 Output: impedance 600 Ω; amplitude 2 V [p-p]
Alarm I/O	7/ 2
Serial Port	1 RS485
Network	10M/100M/1000M Base-TX Ethernet + 100M/1000M SFP
Video Output	1 BNC, impedance 75 Ω; amplitude 1 V [p-p]
GENERAL
Power	DC 48V±25%/DC 24V±15% (DC20V~DC60V) DC -48V±25%/DC -24V±15% (DC-20V~DC-60V) AC 24V±25%
Dimensions (Ø x H)	280.1mm x 364.9mm x 502.8mm (Φ11.0” x 14.4” x19.8”)
Weight	14.5kg (31.9lb)
Working Environment	–40°C ~ +70°C (-40°F ~ 158°F), Humidity :≤95% RH (non-condensing)
Ingress Protection	IP66
