| GENERAL |
| Power: |
DC12V(±25%), PoE+ (IEEE 802.3at) |
| Power Consumption: |
Max 23W |
| Power Interface: |
Ø 5.5mm coaxial power plug |
| Dimensions: |
406 x 126 x 130mm (16.0″ x 5.0″ x 5.1″) |
| Weight: |
2.14kg (4.72lb) |
| Working Environment: |
-40°C ~ 60°C (-40°F ~ 140°F)
Humidity: ≤95% RH (non-condensing) |
| Storage Environment: |
-40°C ~ 70°C (-40°F ~ 158°F)
Humidity: ≤95% RH (non-condensing) |
| Surge Protection: |
6KV |
| Reset Button: |
Support |
| Heater: |
Support |
| CAMERA |
| Sensor: |
1/1.8″ CMOS |
| Min. Illumination: |
Colour: 0.001 lux (F1.6, AGC ON)
0 lux with light |
| Day/Night: |
IR-cut filter with auto switch (ICR) |
| Shutter: |
Auto/Manual, 1 ~ 1/100000s |
| WDR: |
130dB |
| S/N: |
>56 dB |
| LENS |
| Lens Type: |
8 ~ 32 mm |
| Iris Type: |
P-iris |
| Iris: |
F1.6 |
| Field of View (H): |
42.6° ~ 23.5° |
| Field of View (V): |
15.2° ~ 8.9° |
| Field of View (D): |
52.4° ~ 27.7° |
| DORI |
| DORI Distance (Lens): |
8 ~ 32 mm |
| DORI Distance (Detect): |
165.7 m (543.7 ft) ~ 444.4 m (1458.1 ft) |
| DORI Distance (Observe): |
66.3 m (217.5 ft) ~ 177.8 m (583.2 ft) |
| DORI Distance (Recognize): |
33.1 m (108.7 ft) ~ 88.9 m (291.6 ft) |
| DORI Distance (Identify): |
16.6 m (54.4 ft) ~ 44.4 m (145.8 ft) |
| ILLUMINATOR |
| Illumination Distance (IR): |
120 m (394 ft) |
| Illumination Distance (Warm Light): |
30 m (98 ft) |
| Wavelength: |
750 nm |
| IR On/Off Control: |
Auto/Manual |
| PROTECTION |
| Protection: |
IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
IK10 (IEC 62262:2002) |
| VIDEO |
| Video Compression: |
Ultra 265; H.265; H.264; MJPEG |
| Frame Rate – Main Stream: |
4 MP (2688 * 1520), Max 60 fps |
| Frame Rate – Sub Stream: |
2 MP (1920 * 1080), Max 60 fps |
| Frame Rate – Third Stream: |
D1 (720 * 576), Max 60 fps |
| Video Bitrate: |
128 Kbps ~ 16 Mbps |
| ROI: |
Up to 8 areas |
| Video Stream: |
Triple streams |
| OSD: |
Up to 10 OSDs |
| Privacy Mask: |
Up to 8 areas (8 blacks / 8 mosaics) |
| IMAGE |
| White Balance: |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction: |
2D/3D DNR |
| Smart IR: |
Support |
| Flip: |
Flip Vertical/Flip Horizontal/Normal 180°/90° Clockwise/90° Anti-Clockwise |
| HLC: |
Support |
| BLC: |
Support |
| Defog: |
Digital Defog |
| Heatwave Reduction: |
N/A |
| INTELLIGENT |
| Traffic Monitoring: |
Support capturing car license pictures and collecting other car information when the car passes tripwires; Up to 4 lanes can be set; 2 types of application modes available: High/Low pole |
| Smart Intrusion Prevention: |
Support false alarm filtering: Cross line detection, Intrusion detection, Enter area detection, Leave area detection |
| People Counting: |
People counting, support people flow counting and crowd density monitoring (only Channel 1) |
| EVENTS |
| Basic Detection: |
Motion detection; Audio detection; Tampering alarm |
| General Function: |
Watermark; IP Address Filtering; Access Policy; ARP Protection; RTSP Authentication; User Authentication; HTTP Authentication; Alarm input; Alarm output |
| AUDIO |
| Audio Compression: |
G.711U; G.711A |
| Audio Bitrate: |
128 Kbps |
| Two-Way Audio: |
Support |
| Suppression: |
Support |
| Sampling Rate: |
16 KHZ |
| STORAGE |
| Edge Storage: |
Micro SD, up to 256 GB |
| Network Storage: |
ANR; NAS (NFS) |
| NETWORK |
| Protocols: |
SSH; IGMP; RTP; RTCP; SMTP; IPv4; ICMP; ARP; TCP; UDP; DHCP; PPPoE; RTSP; RTMP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; 802.1x; SNMP; QoS; SSL/TLS |
| Compatible Integration: |
ONVIF (Profile S, Profile G, Profile T, Profile M); API; SDK |
| User/Host: |
Up to 3 users; 3 user levels: Administrator, Common User, and Operator |
| Security: |
TLS 1.3; Password protection; Strong password; HTTPS encryption, Export operation logs; Basic and digest authentication for RTSP; Digest authentication for HTTP; TLS 1.2; WSSE and digest authentication for ONVIF |
| Web Browser: |
Plug-in required live view: IE10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above |
| PAN/TILT |
| Home Position: |
Support |
| INTERFACE |
| Audio I/O: |
2/1 |
| Alarm I/O: |
3/2 |
| Serial Port: |
1 channel RS485 interface |
| Built-in Mic: |
2 |
| Built-in Speaker: |
Support |
| Network: |
1 * RJ45 10M/100M Base-TX Ethernet |
