Key Features:
Features:
| Country of Origin | China |
|---|
| Camera | |
|---|---|
| Resolution: | 4MP |
| Sensor: | 1/3.0″ CMOS |
| Min. Illumination: | Colour: 0.003 lux (F1.6, AGC ON) 0 lux with IR on |
| Day/Night: | IR-cut filter with auto switch (ICR) |
| Shutter: | Auto/Manual, 1 ~ 1/100000s |
| Adjustment Angle: | Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360° |
| S/N: | > 52dB |
| WDR: | 120dB |
| Lens | |
| Lens Type: | 2.8 ~ 12mm |
| Iris Type: | Fixed |
| Iris: | F1.6 |
| Field of View (H): | 86.3° ~ 35.2° |
| Field of View (V): | 47.1° ~ 17.0° |
| Field of View (D): | 91.9° ~ 38.6° |
| DORI | |
| DORI Distance (Lens): | 2.8mm ~ 12mm |
| DORI Distance (Detect): | 63m (206.7ft) ~ 270.0m (885.8ft) |
| DORI Distance (Observe): | 25.2m (82.7ft) ~ 108.0m (354.3ft) |
| DORI Distance (Recognize): | 12.6m (41.3ft) ~ 54.0m (177.2ft) |
| DORI Distance (Identify): | 6.3m (20.7 ft) ~ 27.0m (88.6ft) |
| Illuminator | |
| Illumination Distance (IR): | 50m (164ft) |
| Wavelength: | 850nm |
| IR On/Off Control: | Auto/Manual |
| Certification | |
| Protection: | IP67 (IEC 60529) |
| General | |
| Power: | DC 12V±25%, PoE (IEEE 802.3af) |
| Power Consumption: | Max 9.6W |
| Power Interface: | Ø 5.5mm coaxial power plug |
| Dimensions: | 206 x 73 x 73mm (8.1″ x 2.9″ x 2.9″) |
| Weight: | 0.51kg (1.12lb) |
| Material: | Graphene + Metal |
| Working Environment: | -30°C ~ 60°C (-22°F ~ 140°F) Humidity: ≤95% RH (non-condensing) |
| Storage Environment: | -30°C ~ 60°C (-22°F ~ 140°F) Humidity: ≤95% RH (non-condensing) |
| Surge Protection: | 6KV |
| Reset Button: | Support |
| Video | |
| Video Compression: | Ultra 265; H.265; H.264; MJPEG |
| H.264 Code Profile: | Baseline profile, Main profile, High profile |
| Frame Rate – Main Stream: | 4MP (2688*1520), Max 25fps 4MP (2560*1440), Max 25fps 3MP (2304*1296), Max 30fps 1080P (1920*1080), Max 30fps 720P (1280*720), Max 30fps |
| Frame Rate – Sub Stream: | 720P (1280*720), Max 30fps D1 (720*576), Max 30fps 640*360, Max 30fps |
| Video Bitrate: | 128 Kbps ~ 6144 Kbps |
| U-Code: | Support |
| OSD: | Up to 4 OSDs |
| Privacy Mask: | Up to 4 areas |
| ROI: | Up to 8 areas |
| Video Stream: | Dual streams |
| Image | |
| White Balance: | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction: | 2D/3D DNR |
| Smart IR: | Support |
| Flip: | Normal/Flip Vertical/Flip Horizontal/180°/90° Clockwise/90° Anti-clockwise |
| Dewarping: | N/A |
| HLC: | Support |
| BLC: | Support |
| Defog: | Digital Defog |
| Events | |
| Basic Detection: | Cross line; Intrusion (based on human body detection); Motion detection; Ultra motion detection; Tampering alarm; Audio detection |
| General Function: | Watermark; IP Address Filtering; Access Policy; ARP Protection; RTSP Authentication; User Authentication; HTTP Authentication |
| Audio | |
| Audio Compression: | G.711U; G.711A |
| Audio Bitrate: | 64 Kbps |
| Two-Way Audio: | N/A |
| Suppression: | Support |
| Sampling Rate: | 8KHZ |
| Storage | |
| Edge Storage: | Micro SD, up to 256GB |
| Network Storage: | ANR; NAS (NFS) |
| Network | |
| Protocol: | IPv4; IGMP; ICMP; ARP; TCP; UDP; DHCP; RTP; RTSP; RTCP; RTMP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; SMTP; SSL/TLS; QoS; SNMP |
| Compatible Integration: | ONVIF (Profile S, Profile G, Profile T); API; SDK |
| User/Host: | Up to 32 users; 2 user levels: Administrator and Common User |
| Web Browser: | Plug-in required live view: IE10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above |
| Interface | |
| Audio I/O: | N/A |
| Alarm I/O: | N/A |
| Serial Port: | N/A |
| Built-in Mic: | Support |
| Built-in Speaker: | N/A |
| WiFi: | N/A |
| Network: | 1 * RJ45 10M/100M Base-TX Ethernet |
| Video Output: | N/A |
