| Camera |
| Resolution: |
8MP |
| Sensor: |
1/2.8″ CMOS |
| Min. Illumination: |
Colour: 0.0025 lux (F1.6, AGC ON)
0 lux with IR |
| Day/Night: |
IR-cut filter with auto switch (ICR) |
| Shutter: |
Auto/Manual, 1 ~ 1/100000s |
| Adjustment Angle: |
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotate: 0° ~ 360° |
| S/N: |
> 52dB |
| WDR: |
120dB |
| Lens |
| Lens Type: |
2.8 ~ 12mm |
| Iris Type: |
Fixed |
| Iris: |
F1.6 |
| Field of View (H): |
107.4° ~ 29.2° |
| Field of View (V): |
54.2° ~ 16.3° |
| Field of View (D): |
111.0° ~ 33.1° |
| Zoom: |
Motorized |
| DORI |
| DORI Distance (Lens): |
2.8mm ~ 12mm |
| DORI Distance (Detect): |
86.9m (285.1ft) ~ 372.4m (1121.8ft) |
| DORI Distance (Observe): |
34.8m (114.2ft) ~ 149.0m (488.8ft) |
| DORI Distance (Recognize): |
17.4m (57.1ft) ~ 74.5m (244.4ft) |
| DORI Distance (Identify): |
8.7m (28.5ft) ~ 37.2m (112.0ft) |
| Illuminator |
| Illumination Distance (IR): |
50m (164ft) |
| Wavelength: |
850nm |
| IR On/Off Control: |
Auto/Manual |
| Certification |
| Protection: |
IP67 (IEC 60529)
IK10 (IEC 62262) |
| General |
| Power: |
DC 12V±25%, PoE (IEEE 802.3af) |
| Power Consumption: |
Max 10.5W |
| Power Interface: |
Ø 5.5mm coaxial power plug |
| Dimensions: |
245 x 86 x 72mm (9.6″ x 3.4″ x 2.8″) |
| Weight: |
0.92kg (2.03lb) |
| Material: |
Metal |
| Working Environment: |
-30°C ~ 60°C (-22°F ~ 140°F)
Humidity: ≤95% RH (non-condensing) |
| Storage Environment: |
-30°C ~ 60°C (-22°F ~ 140°F)
Humidity: ≤95% RH (non-condensing) |
| Surge Protection: |
6KV |
| Reset Button: |
Support |
| Video |
| Video Compression: |
Ultra 265; H.265; H.264; MJPEG |
| H.264 Code Profile: |
Baseline Profile, Main Profile, High Profile |
| Frame Rate – Main Stream: |
8MP (3840*2160), Max 20fps
5MP (3072*1728), Max 30fps
4MP (2560*1440), Max 30fps
1080P (1920*1080), Max 30fps |
| Frame Rate – Sub Stream: |
1080P (1920*1082), Max 30fps
720P (1280*720), Max 30fps
D1 (720*576), Max 30fps
640*360, Max 30fps
2CIF (704*288), Max 30fps
CIF (352*288), Max 30fps |
| Frame Rate – Third Stream: |
D1 (720*576), Max 30fps
640*360, Max 30fps
2CIF (704*288), Max 30fps
CIF (352*288), Max 30fps |
| Video Bitrate: |
128 Kbps ~ 16 Mbps |
| U-Code: |
Support |
| OSD: |
Up to 8 OSDs |
| Privacy Mask: |
Up to 4 areas |
| ROI: |
Up to 8 areas |
| Video Stream: |
Triple streams |
| Image |
| White Balance: |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction: |
2D/3D DNR |
| Smart IR: |
Support |
| Flip: |
Normal/Vertical/Horizontal/180°/90° Clockwise/90° Anti-clockwise |
| Dewarping: |
Support |
| HLC: |
Support |
| BLC: |
Support |
| Defog: |
Digital Defog |
| Intelligent |
| Smart Intrusion Prevention: |
Support false alarm filtering; Cross line detection; Intrusion detection; Enter area detection; Leave area detection |
| Statistical Analysis: |
People counting; support people flow counting and crowd density monitoring |
| Events |
| Basic Detection: |
Motion detection; Ultra motion detection; Tampering alarm; Audio detection |
| General Function: |
Watermark; IP Address Filtering; Access Policy; ARP Protection; RTSP Authentication; User Authentication; HTTP Authentication |
| Audio |
| Audio Compression: |
G.711U; G711A |
| Audio Bitrate: |
64 Kbps |
| Two-Way Audio: |
Support |
| Suppression: |
Support |
| Sampling Rate: |
8KHZ |
| Storage |
| Edge Storage: |
Micro SD, up to 256GB |
| Network Storage: |
ANR; NAS (NFS) |
| Network |
| Protocol: |
IPv4; IPv6; IGMP; ICMP; ARP; TCP; UDP; DHCP; PPPoE; RTP; RTSP; RTCP; RTMP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; SMTP; SSL/TLS; 802.1x; SNMP; SSH |
| Compatible: |
ONVIF (Profile S, Profile G, Profile T); API; SDK |
| User/Host: |
Up to 32 users; 3 user levels: Administrator, Common User, and Operator |
| Web Browser: |
Plug-in required live view: IE10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above |
| Interface |
| Audio I/O: |
Input: impedance 35kΩ; amplitude 2V [p-p]
Output: impedance 600Ω; amplitude 2V [p-p] |
| Alarm I/O: |
1/1 |
| Built-in Mic: |
N/A |
| Built-in Speaker: |
N/A |
| WiFi: |
N/A |
| Serial Port: |
N/A |
| Network: |
1 * RJ45 10M/100M Base-TX Ethernet |
| Video Output: |
N/A |
