Analog Bullet Cameras, Analog HD - All-in-One Security Cameras
2MBT-4KIR20 4K TVI Bullet Camera Fixed Lens
- 4-in-1 bullet camera
- 1/2.8″Sony 415 CMOS 8.0M+FH8556
- 18pcs SMD LEDs
- 20m IR Range
Product Documents
Downloads
- 4-in-1 bullet camera
- 1/2.8″Sony 415 CMOS 8.0M+FH8556
- 18pcs SMD LEDs
- 20m IR Range
- Standard match 2.8mm lens
- WDR
- Default TVI output
| Lens | Fixed 2.8mm Lens |
|---|---|
| Resolution | 4k – 8 Megapixel (3840 x 2160) |
| Signal Type | |
| Night Vision Type | Infra Red (IR) LED |
| Night Vision Distance | 20 Meters (65 feet) |
| Country of Origin | China |
| System | NTSC |
| Sensor | IMX415 1/2.8 |
| DSP | FH8556 |
| Active Pixel | 3840*2160 |
| SYNC. | Internal |
| Resolution | 8MP |
| Video Out | TVI:8M@15fps,[email protected]
AHD:8M@15fps CVI:8M@15fps,[email protected] CVBS:PAL,NTSC |
| Minimum Illumination | 0.01Lux(F1.2) |
| Gama adjust | 0.45 |
| S/N Ratio | 50dB(min)(AGC closed) |
| AE | GLOBE/BLC |
| AWB | PRO/GRAY WORLD/ATW/MWB |
| 3DNR | AUTO/MANUAL(0-10) |
| OSD | Yes |
| Language | Eng Chin1 Chin2 Русс ESPA FRAN POL ITAL PORT JAPA |
| Day/Night | Auto, Color, Mono, Ext |
| Power Input | DC12V±1V |
| Power Dissipation | 175mA-180mA |
| Transmission distance | 75-5 300M |
| Operation Temperature | Temperature -10℃～+55℃,Humidity less than 85%RH |
| Weight | 0.75kgs |
| Color | White+black |
