Explosion Proof, Explosion Proof Accessories, Explosion Proof Monitors
2MEM ATEX, IECEX Certified Explosion Proof Box
- Features:
- Size 441 x 200 x 348 mm / 17.3 x 7.8 x 13.7″ (in)
- Screen TFT-LCD, 15inch
- Resolution 1024 x 768
- Brightness 220 units
- Contrast 700:1
- Response Time 8/4 (Tr/Td) ms
Note: This is a special order camera. Allow 4-6 weeks for delivery.
Product Documents
Downloads
| CERTIFICATION | |
| Certificate Mark | ExdIIB T6 Gb / Ex tD A21 IP68 T80°C |
| Certificate No | CNEx19.0326 |
| Standards | Q/320412ZAF014-2018 |
| MECHANICAL | |
| Housing | Carbon steel, Stainless steel 304 or 316L |
| IP | IP68 |
| Cable thread hole | 4pcs G3/4 or NPT3/4 or M25*1.5 |
| ELECTRICAL | |
| Voltage | AC100-240V |
| Power | 50W |
| Surge Protect | Optional, TVS6000V surge protect |
| AMBIENT | |
| Ambient temperature | -25 to +60°C / -13 to 140°F |
| Air pressure | 80Kpa to 106Kpa |
| Relative Humidity | 95% (no condensation) |
| FUNCTION | |
| Screen | TFT-LCD, 15inch |
| Resolution | 1024 x 768 |
| Brightness | 220 nits |
| Contrast | 700:1 |
| Response Time | 8/4 (Tr/Td) ms |
Note: This is a special order camera. Allow 4-6 weeks for delivery.
| Weight | 61 lbs |
|---|---|
| Dimensions | 17 × 7.8 × 13.7 in |
| Country of Origin | China |
| CERTIFICATION | |
| Certificate Mark | ExdIIB T6 Gb / Ex tD A21 IP68 T80°C |
| Certificate No | CNEx19.0326 |
| Standards | Q/320412ZAF014-2018 |
| MECHANICAL | |
| Housing | Carbon steel, Stainless steel 304 or 316L |
| IP | IP68 |
| Cable thread hole | 4pcs G3/4 or NPT3/4 or M25*1.5 |
| ELECTRICAL | |
| Voltage | AC100-240V |
| Power | 50W |
| Surge Protect | Optional, TVS6000V surge protect |
| AMBIENT | |
| Ambient temperature | -25 to +60°C / -13 to 140°F |
| Air pressure | 80Kpa to 106Kpa |
| Relative Humidity | 95% (no condensation) |
| FUNCTION | |
| Screen | TFT-LCD, 15inch |
| Resolution | 1024 x 768 |
| Brightness | 220 nits |
| Contrast | 700:1 |
| Response Time | 8/4 (Tr/Td) ms |
