GENERAL
Material: Steel Q235
Rating: Rated for outside use
Dimensions (LxWxH): 2000×1050×4100 (mm); 6.6×3.4×13.5 (ft)
Shipping Dimensions: 1050×1050×600 (mm); 3.4×3.4×2.0 (ft)
Transport Dimensions: 1050×1050×2800 (mm); 3.4×3.4×9.2 (ft)
Weight: 375kg / 827lb
System Voltage: DC12V
Work Temperature: -0ËšC~45ËšC / 32ËšF~113ËšF
SOLAR SYSTEM
Solar Panel: 1 × 460W Monocrystalline Silicon; 72pcs
Voltage: DC49V
Charging Time: 4.4 Hours
CCTV SYSTEM
Box: Square
Device: PoE Switch
Running Time: 48 hours for 40W
MAST SYSTEM
Body: Steel Q235; Galvanized
Fastener: Stainless steel 304
Wire Rope: Stainless steel 316; 4mm
Type: Square, Telescopic
Height: 3.5m / 11.5ft
Section: 3
Spring Cable: Power Supply
Lifting Method: Manual Winch
Recommended Load: 5kg ~ 50kg / 11lb ~ 110lb
Windproof: 117km/h / 73mph
BATTERY SYSTEM
LFP: 1x 200 Ah
Voltage: DC12V
Power Capacity: 2400W/h
CONTROL SYSTEM
Solar Controller MPPT; 40A
Efficiency: 95%+
Detection & Protection: Short-Circuit, Overload, High Voltage, High Temperature
Timer: Dusk & Dawn
Whole Machine: Battery Isolator; Device on-off
BASE SYSTEM
Base: Galvanized, Durable
Fixed Ring: 4
Forklift Hole: 4
Warranty: 2 years
ACCESSORIES
Includes Operation manual, controller manual, parts manual, allen wrench and hex wrench
CERTIFICATION
Certificates: ISO9001, ISO14001, OHSAS 18001, CE
