2MVT-5MIR40ZSL 5MP Outdoor Dome Camera with Starlight
- 1/2.8″SONY Starvis Back-illuminated CMOS sensor
- 4-IN-1 Signal (TVI/AHD/CVI/CVBS)
- 2.7-13.5mm Motorized Lens
- IR Distance max 40m
- IP67 outdoor, OSD & UTC support
Product Documents
Downloads
2MCCTV brings you our 2MP HD Motorized Eyeball Camera is a smart, high tech security camera. The device offers up to 5 megapixels resolution recording and AF automatic focusing and motorized zoom lenses. In addition, the camera includes 42 IR LEDs to help provide illumination in poorly lit areas up to 30-40 meters IR distance. Lastly, the camera has a durability rating of IP66.
- 1/2.8″SONY Starvis Back-illuminated CMOS sensor
- 4-IN-1 Signal (TVI/AHD/CVI/CVBS)
- 2.7-13.5mm Motorized Lens
- IR Distance max 40m
- IP67 outdoor, OSD & UTC support
| Weight | 1.45 lbs |
|---|---|
| Resolution | 5 Megapixel (2560 x 1960) |
| Lens | Motorized 2.8-12mm Lens |
| Night Vision Type | Infra Red (IR) LED |
| Vandal Resistant | IK10 |
| Country of Origin | China |
|
Video Output Mode |
AHD: 8M@15fps, 5M@20fps/12.5fps, 4MP@30fps/25fps/15fps; 2M@30fps/25fps; CVI: 8M@15fps/12.5fps, 4M/2M@30fps/25fps;
TVI: 8M@15fps/12.5fps, 5M@20fps/12.5fps, 4M/2M@30fps/25fps |
| Camera | |
| Image Sensor | 1/2.8″ SONY Starvis Back-illuminated CMOS sensor |
| Image Resolution | 8M:3840*2160 5M:2592*1944 4M:2560*1440 2M:1920*1080 |
| TV System | PAL/NTSC |
| Electronic Shutter | AUTO / MANUAL |
| Scanning System | Progressive Scan |
| Lens | |
| Focus Length | 2.7-13.5mm |
| Focus Control | Auto |
| Lens Type | Motorized |
| Night Vision | |
| IR Cut Filter | YES |
| Infrared LED | 42µ x 4PCS |
| Infrared Distance | 40M |
| IR Power On / Off | AGC Auto Control |
| Camera Features | |
| Starlight | YES |
| Day/Night | YES |
| OSD Menu | YES |
| WDR | YES |
| UTC | YES |
| Noise Reduction | 3DNR |
| White Balance | AUTO / MANUAL |
| Gain Control | AUTO |
| General | |
| Housing | Metal, IP67 |
| Bracket | NO |
| Operation Temperature | -10℃ ~ +60℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%, 750mA |
| Dimension | φ136 x 148(H)mm |
| Weight | 1700g |
